Arrow Pneumatics Piggyback Filter Regulator
| Features |
| • 40 Micron element |
| • Manual Drain |
| • Relieving regulator |
| • Zero creep, machined brass valve seat |
| • 3-position, non-rising adjustment knob |
| • Tamper-proof cap included |
| Specifications | |
| Body | • black E-coated aluminum |
| Bonnet | • Glass filled nylon |
| Seals | • Buna N Elastomer standard |
| Polycarbonate Bowl | • Max pressure 150 psig |
| • Operating pressure range 5 to 125 psi | |
| • Operating temperature range 40° to 125°F | |
| Warning! Polycarbonate plastic bowls could rupture if exposed to incompatible chemicals whether inside or outside the bowl. If such chemicals are present, use a metal bowl. | |
| Pipe Size | Model Number | Max Flow SCFM | Bowl Capacity | Dimensions (In) | Weight (Lbs.) | ||||
| A | B | C | D | E | |||||
| 3/4" | B756G | 100 | 5 oz | 2 21/32 | 4 5/32 | 9 3/4 | 2 1/4 | 2 3/4 | 3 |
